Titanium Nano Coatings

The titanium and its alloy powder are refined to nanometer level, so that its surface activity is greatly improved, meanwhile, the polymer resin double bond is opened to form the free bond, and the two hybrids are combined to form a titanium nano-polymer The coating of the titanium nano-polymer as active filler of polymer alloy is titanium nano-polymer coating

It is characterized by:


1. Strong adhesion: Level I
2. Strong resistance to penetration
Titanium nano-polymers and resins form chemical bonding and chemical adsorption, cutting off the osmotic channel between the filler and the resin. Tiny Titanium nano-polymer particles can fill hole defects and prevent the penetration and transmittance of corrosive dielectric ions.
3. Strong corrosion resistance of the material itself
The coating itself has strong corrosion resistance, and also has shielding effect and hydrophobic effect, so can effectively play the anti-corrosion effect.
4. Good anti-scaling performance
5. Good thermal conductivity
6. High temperature resistance
7. Good wear Resistance
8.Good anti-cavitation performance


Technical parameters


Testing unit: National coatings Quality Supervision and Inspection Center


Serial number

Testing items

Test results

Note

1

Impact resistant cm

50

GB/T1732-93

2

Flexibility

1

GB/T1731-93

3

Adhesion (paddle spacing 1mm) level

A

GB/T9286-1998

4

Adhesion (Pull method)Mpa

4.7*A

GB/T5210-2006

5

Bending test (cylindrical shaft) mm

2

GB/T6742-2007

6

Hardness S

133

GB/T1730-2007 A

7

Wear resistance 1000g/1000rg

0.014

GB/T1798-2008

8

Water resistance (immersed in boiling water 8h )

No change

GB/T1733-93 B

9

Gasoline resistant (immersed in 90# gasoline 7d)

No change

GB/T1734-93 A

10

Alkaline resistance (immersion in 20%NaOH 7d)

No change

GB/T9278-2008 A

11

Saline resistance (immersed in boiling NaCl solution 8h)

No change

GB/T9274-88 A

12

Acidic resistance (immersed in 10%,30%HCL,HNO3,H2SO4 7d respectively)

No change

GB/T9274-88 A

13

H2S (2.5MPa) CO2 (2.5MPa) 80 ℃ ,immersed 7d

No change



14

Usage temperature

-40 ---+300℃
